18 Frame Radial Extractor - Fully Programmable

$7 618.00
Price incl. GST (15%) $993.65
In stock: 6 available
Product Details
Brand: LYSON

18 Frame (Langstroth) Radial honey extractor, Ø720 mm, electric drive, CLASSIC Line. Automatic controller.

Automatic control has eight programs. The first two programs are designed to work in manual mode, the third program - automatic, has factory settings. Programs from 4 to 8 (automatic) allow you to enter your own settings. Each program consists of 7 steps. At each step, you can set three parameters - step start time, set speed and direction of rotation. The seventh, last step defines the time of stopping the basket of honey extractor.

Specifications:

Product line CLASSIC
Honey extractor type Radial
Drum diameter Ø720
Power 230V
Frive Electric, bottom mounted motor
Contoller HE-02N
Power 0.37kW geared motor
Thickness of drum wall 0.6 mm
Thickness of plexiglass lid 4 mm
Valve Stainless 6/4"
Top bar A flat bar 100 × 10 mm, powder coated
Legs Powder coated 50 x 30 mm
Hinges Plastic, 4 pcs
Drum height 640 mm
Drum support Powder coated
Strengthening cross Powder coated
Stainless steel rod Ø10 and Ø8 mm
Shipped Crated on Pallet
Guarantee

Guarantee 5 years

Guarantee for electrical components, controller, motor and drive components 2 years



The Lyson 18 frame fully automatic extractor, model W201000, is a radial honey extractor designed for beekeeping operations. It features an electric drive and an automatic controller that comes with eight programmable settings to facilitate the extraction process. The extractor is part of the CLASSIC line offered by Lyson Beekeeping Supplies and is designed to accommodate 18 frames. The diameter of the extractor is 720 mm, which allows for a significant amount of honey to be processed at once.The automatic controller's eight programs are designed to make the extraction process more efficient, with the first two programs being pre-set for immediate use. This feature provides beekeepers with the flexibility to choose the best extraction program for their specific needs, potentially improving honey yield and preserving the quality of the honeycomb.The Lyson 18 frame extractor is one of several extractors in the Classic Line, with other options including a 30 frame model (W2005000), a 42 frame model (W2007000) and a 56 frame model (W2008000).
